Hitachi CB 520H A1 User Manual

Key Operation / Roll
Operation Performing
Screen
Displays the PCI device mapping
information.
PCI Device Information
Displays the VLAN ID assignment and
promiscuous mode setting list on a sub-
screen in the VNIC Assignment screen.
Virtual NIC Assignment
Deletes a user from user authentication. System Configuration
F3 Activates (powers on) an LPAR. LPAR manager Menu
Logical Partition
Configuration
Changes the password used for user
authentication.
System Configuration
F4 Deactivates (powers off) an LPAR. LPAR manager Menu
Logical Partition
Configuration
F5 Reactivates (restarts) an LPAR. LPAR manager Menu
Logical Partition
Configuration
Switches USB devices assignment. PCI Device Assignment
Sets the promiscuous mode. Virtual NIC Assignment
F6 Adds (defines) an LPAR. LPAR manager Menu
Logical Partition
Configuration
Change USB auto attach settings PCI Device Assignment
Changes the MAC address. Virtual NIC Assignment
Changes LPAR manager system time Date and Time
F7 Deletes an LPAR. LPAR manager Menu
Logical Partition
Configuration
Sets the VLAN mode. Virtual NIC Assignment
Changes LPAR manager system time zone Date and Time
F8 Switches to display of a guest screen. LPAR manager Menu
Logical Partition
Configuration
Sets the packet filter for communication
between LPARs.
Virtual NIC Assignment
F9 Saves the LPAR manager configuration to
the non-volatile storage in the Switch and
Management Module.
LPAR manager Menu
Logical Partition
Configuration
[LPAR manager firmware version 01-9X or
later]
Virtual NIC Assignment
Operation by LPAR manager Screen
7-3
Hitachi Compute Blade 500 Series Logical partitioning manager User's Guide
