Table 1-9 Example for CB 520A A1 when Onboard LAN Card is not installed
(Emulex 10Gb 4ports)
Physical NIC
Physical Port
No.
1
Logical Port
No.
2
Detection No.
of LAN
controller
Network
segment
Mezzanine Card
1
(Emulex 10Gb
4ports)
0 2 2 2a
1 3 2b
2 0 1 1a
3 1 1b
Notes:
1. The physical port number which exists on the system.
2. The logical port number which displays on the LPAR manager screen.
Table 1-10 Example for CB 540A A1/B1, CB 520X B1/B2/B3 when Onboard
LAN Card is not installed (Emulex 10Gb 4ports)
Physical NIC
Physical Port
No.
1
Logical Port
No.
2
Detection No.
of LAN
controller
Network
segment
Mezzanine Card
1
(Emulex 10Gb
4ports)
0 0 1 1a
1 1 1b
2 2 2 2a
3 3 2b
Mezzanine Card
3
(Emulex 10Gb
4ports)
3
0 0 3 3a
1 1 3b
2 2 4 4a
3 3 4b
Notes:
1. The physical port number which exists on the system.
2. The logical port number which displays on the LPAR manager screen.
3. NIC cannot be installed on Mezzanine Card 3 for CB 520X B1.
Table 1-11 Example for CB 520H A1/B1/B2/B3/B4 when Onboard LAN
Card is not installed (Broadcom 1Gb 4ports)
Physical NIC
Physical Port
No.
1
Logical Port
No.
2
Detection No.
of LAN
controller
Network
segment
Mezzanine Card
1
0 0 1 1a
1 1 1b
1-24
LPAR manager Functions
Hitachi Compute Blade 500 Series Logical partitioning manager User's Guide
