65
3. Web Control
The Main window as shown above is displayed at first. However, if you have
enabled User Password on the Tools window (
69), a dialog prompting you to
enter the password as shown on the right will be displayed, and no operation is
enabled until you have entered the password. After entering the preset password,
the dialog disappears and the Main window will be displayed.
As shown below, you can open a window by clicking the corresponding tab at the
top right of the window.
3.2 Crestron e-Control
®
User Password dialog
Tab
Tab Description
Logout
Logs out from e-Control
®
.
This tab appears only when User Password of the Tools window is
enabled.
Tools Opens Tools window. (
69)
Info Opens Info window. (
71)
Contact IT Help Opens Help Desk window. (
72)
CP-X9110/WX9210/WU9410
CP-X9111/WX9211/WU9411
CP-HD9320/HD9321
User Password dialog
CP-X9110/WX9210/WU9410
CP-X9111/WX9211/WU9411
CP-HD9320/HD9321
