Hitachi L200 Series User Manual

“A” Group: Standard Functions
Configuring
Drive Parameters
3–28
Additional Analog Input Settings
Input Range Settings – The parameters in the following table adjust the input charac-
teristics of the analog current input. When using the inputs to command the inverter
output frequency, these parameters adjust the starting and ending ranges for the current,
as well as the output frequency range. Related characteristic diagrams are located in
“
Analog Input Settings” on page 3–14.
“A” Function
Run
Mode
Edit
Defaults
Func.
Code
Name /
SRW Display
Description
–FEF
(EU)
–FU
(USA)
Units
A101 [OI]–[L] input active
range start frequency
The output frequency corre-
sponding to the current input
range starting point.
Range is 0.00 to 400.0 Hz
✘ 0.0 0.0 Hz
OI-EXS 0000.0Hz
A102 [OI]–[L] input active
range end frequency
The output frequency corre-
sponding to the current input
range ending point.
Range is 0.00 to 400.0 Hz
✘ 0.0 0.0 Hz
OI-EXE 0000.0Hz
A103 [OI]–[L] input active
range start current
The starting point for the
current input range.
Range is 0. to 100.%
✘ 0.0 0.0 %
OI-EX%S 00000%
A104 [OI]–[L] input active
range end current
The ending point for the
current input range.
Range is 0. to 100.%
✘ 100. 100. %
OI-EX%E 00100%
A105 [OI]–[L] input start
frequency enable
Two options:
00...Use A101 start value
01...Use 0Hz
✘ 01 01 —
OI-LVL 0Hz

Hitachi L200 Series Specifications

General

Output Frequency	0.1-400Hz
Communication	RS-485 (Modbus RTU)
Frequency Range	0.1-400Hz
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Input Voltage	200-240V
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Output Voltage	3-phase, 0 to input voltage
Cooling Method	Forced air cooling
Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000m without derating
Braking Unit	Built-in braking transistor (for models up to 7.5kW), External braking resistor can be connected
