Hitachi L200 Series User Manual

L200 Inverter
Appendix C
C–9
Intelligent Terminal Functions
“C” Group Parameters Default Setting
User
Setting
Func.
Code
Name
-FEF
(EU)
-FU
(USA)
C001 Terminal [1] function 00 00
C002 Terminal [2] function 01 01
C003 Terminal [3] function 02 16
C004 Terminal [4] function 03 13
C005 Terminal [5] function 18 09
C011 Terminal [1] active state 00 00
C012 Terminal [2] active state 00 00
C013 Terminal [3] active state 00 00
C014 Terminal [4] active state 00 01
C015 Terminal [5] active state 00 00
C021 Terminal [11] function 01 01
C022 Terminal [12] function 00 00
C026 Alarm relay terminal function 05 05
C028 [AM] signal selection 00 00
C031 Terminal [11] active state 00 00
C032 Terminal [12] active state 00 00
C036 Alarm relay active state 01 01
C041 Overload level setting Inverter
rated
current
Inverter
rated
current
C042 Frequency arrival setting for
acceleration
0.0 0.0
C043 Arrival frequency setting for
deceleration
0.0 0.0
C044 PID deviation level setting 3.0 3.0
C052 PID FBV function high limit 100.0 100.0
C053 PID FBV function low limit 0.0 0.0
C071 Communication speed selection 06 04
C072 Node allocation 1. 1.
C074 Communication parity selection 00 00
C075 Communication stop bit selection 1 1
C076 Communication error select 02 02

Hitachi L200 Series Specifications

General

Output Frequency	0.1-400Hz
Communication	RS-485 (Modbus RTU)
Frequency Range	0.1-400Hz
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Input Voltage	200-240V
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Output Voltage	3-phase, 0 to input voltage
Cooling Method	Forced air cooling
Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000m without derating
Braking Unit	Built-in braking transistor (for models up to 7.5kW), External braking resistor can be connected
