Hitachi L200 Series

Orientation to Inverter Features
Inverter Mounting
and Installation
2–4
Logic Connector Introduction
After removing the front housing cover, take a moment to become familiar with the
connectors, as shown below.
Logic and analog
signal connections
Relay output
contacts
