Hitachi L200 Series - ModBus Holding Registers (A Group Standard Functions - Continued)

ModBus Data Listing
Appendix B
B–30
A095 Acc1 to Acc2 frequency
transition point
R/W Output frequency at which
Accel1 switches to Accel2,
range is 0.0 to 400.0 Hz
007Eh 0 to 4000 0.1 Hz
A295 Acc1 to Acc2 frequency
transition point, 2nd
motor
R/W 007Fh
A096 Dec1 to Dec2 frequency
transition point
R/W Output frequency at which
Decel1 switches to Decel2,
range is 0.0 to 400.0 Hz
0080h 0 to 4000 0.1 Hz
A296 Dec1 to Dec2 frequency
transition point, 2nd
motor
R/W 0081h
A097 Acceleration curve
selection
R/W Set the characteristic curve of
Acc1 and Acc2, two options:
00...linear
01...S-curve
0082h 0, 1 —
A098 Deceleration curve
selection
R/W Set the characteristic curve of
Acc1 and Acc2, two options:
00...linear
01...S-curve
0083h 0, 1 —
A101 [OI]–[L] input active
range start frequency
R/W The output frequency corre-
sponding to the current input
range starting point.
Range is 0.00 to 400.0 Hz
0084h 0 to 4000 0.1 Hz
A102 [OI]–[L] input active
range end frequency
R/W The output frequency corre-
sponding to the current input
range ending point.
Range is 0.00 to 400.0 Hz
0085h 0 to 4000 0.1 Hz
A103 [OI]–[L] input active
range start current
R/W The starting point for the
current input range.
Range is 0. to 100.%
0086h 0 to 100 1 %
A104 [OI]–[L] input active
range end current
R/W The ending point for the
current input range.
Range is 0. to 100.%
0087h 0 to 100 1 %
A105 [OI]–[L] input start
frequency enable
R/W Two options:
00...Use A101 start value
01...Use 0Hz
0088h 0, 1 —
A141 A input select for calcu-
late function
R/W Five options:
00...Digital operator
01...Keypad potentiometer
02...[O] input
03...[OI] input
04...Network variable
00E3h 0 to 4 —
Holding Registers for “A” Group Standard Functions
Func.
Code
Name R/W Description
Network Data
Reg. Range Res.
