Hitachi L200 Series User Manual

L200 Inverter
Configuring
Drive Parameters
3–19
A244 V/f characteristic curve
selection, 2nd motor
Two available V/f curves;
three select codes:
00...Constant torque
01...Reduced torque
✘ 02 02 —
2CTRL C-TRQ
A045 V/f gain setting Sets voltage gain of the
inverter, range is 20. to 100.%
✔ 100. 100. %
V-Gain 00100%
“A” Function
Run
Mode
Edit
Defaults
Func.
Code
Name /
SRW Display
Description
–FEF
(EU)
–FU
(USA)
Units

Hitachi L200 Series Specifications

General

Output Frequency	0.1-400Hz
Communication	RS-485 (Modbus RTU)
Frequency Range	0.1-400Hz
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Input Voltage	200-240V
Control Method	V/f control, Sensorless vector control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Output Voltage	3-phase, 0 to input voltage
Cooling Method	Forced air cooling
Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000m without derating
Braking Unit	Built-in braking transistor (for models up to 7.5kW), External braking resistor can be connected
