An example is shown in the following figure:
Fd – Upper heating temperature setting limit
This function is used to define an upper temperature setting limit for the HEAT function. This function enables the heating
range to be reduced for configuration using the remote control. The setting condition is shown below.
Setting
Contents
00 Standard
01 Lower limit -1 °C
02 Lower limit -2 °C
03-08 Lower limit -(03-08) °C
09 Lower limit -9 °C
10 Lower limit -10 °C
An example is shown in the following figure:
FE – Not used
Setting
Contents
00 Not available
01
Used as setting for conditions 00
02
FF – ON/OFF timer function interlock
This function is used to lock timer activation.
Setting condition
Contents
00 Not available
01 Available (factory setting)
H1 – Maintenance alarms
This function is used to display or hide maintenance alarms.
Setting condition
Contents
00 Display
01 Hide
6 Optional functions
217
SMGB0063 rev. 1 - 10/2010
