Number Part name Remarks
U00A Printed circuit board terminals —
U02 SW remote control PC-ART (optional)
U13 Electrical box Assembly of (components + harness)
U14 Capacitor 2.5uF
U15A Thermistor THM3 thermistor for liquid piping
U15B Thermistor THM5 thermistor for gas pipe
U15C Thermistor THM1 thermistor for air inlet
U15D Thermistor THM2 thermistor for air outlet
U21 Expansion valve —
U31 Filter —
U36 Fan casing/Runner Fan casing + runner
U37 Fan casing/Runner Fan casing + runner
U41 Heat exchanger Assembly
U65A Spacer For the fixed PCB
U65B push spacer For the fixed PCB
U71A Fan motor —
U71B Drain pump Kit DU-M1E (optional)
U82 Transformer —
U85 Printed circuit board PI073 (main PCB)
U87 Float sensor —
U97 Drain pan Assembly
