Press the RESET switch on the remote control.
C A U T I O N
• Never wash filters in hot water.
• Do not scrub the filters.
• Do not expose the filters to flames.
N O T E
• R15 and R19 type filters can only be washed to a certain point.
• R17, R50 and R20 filters can be washed thoroughly.
• R series filters can be washed in warm water (30-40 °C) with neutral soap. The filters can be dried on a flat
surface. They can also be cleaned using compressed air, applying it in the opposite direction to the filter air
flow.
KPI-3002H2E
Open the filter access door.
Remove the filters.
Use a vacuum cleaner to suck up any dust.
Dissolve a little neutral soap in cold or warm water to clean the dirt.
Place the filters in the soapy water to clean them.
Allow the filters to dry.
Fit the filter.
Close the service cover.
Press the RESET switch on the remote control.
10 Servicing
354
SMGB0063 rev. 1 - 10/2010
