Hitachi VSP 5000 Series - Extension MIB Specifications; Extension MIB Configuration

An SNMP Agent mounts only system groups in mib-2, as shown in the following table.
Name Description Mounted value
sysObjectID
{system 2}
This is the product
identication number.
Fixed value. See Object identier system
(on page 45) .
1.3.6.1.4.1.116.3.11.4.1.1
sysUpTime
{system 3}
An accumulated time from
an SNMP agent.
Unit: 100 ms
sysContact
{system 4}
A manager who manages an
agent or a contact address.
Maximum 180 characters in an ASCII
characters string. Input by a user from an
SNMP setting window.*
sysName
{system 5}
The name of an agent
manager
Maximum 180 characters in an ASCII
characters string. Input by a user from an
SNMP setting window.*
sysLocation
{system 6}
An agent setup location. Maximum 180 characters in an ASCII
characters string. Input by a user from an
SNMP setting window.*
sysService
{system 7}
Value indicating a service. Fixed value 76 (decimal)
*The following symbols cannot be used: \ , / : ; * ? " < > | & % ^
Extension MIB specifications
Extension MIB configuration
The following shows the extension MIB object system for the storage system.
raidExMibRoot(1)
├-raidExMibName(1) SVP product name
├-raidExMibVersion(2) SVP Micro-program version
├-raidExMibAgentVersion(3) Extension MIB internal version
├-raidExMibDkcCount(4) Number of DKC under the control of SVP
├-raidExMibRaidListTable(5) List of DKC under the control of SVP
├-raidExMibDKCHWTable(6) Disk control device information
├-raidExMibDKUHWTable(7) Disk device information
├-raidExMibTrapListTable(8) Error information list
The following gures show an example extension MIB conguration.
