Trap reference
code
Description Section Alert level
Host
report
1
SIM
22
SIM
23
SIM
13
 f7 xx GUM blocking Cache MODERAT
E
Yes
 f9 0x REPLACE FAILED Cache SERVICE No
 fa xx Battery warning Battery MODERAT
E
No
 fb xx CMBK warning Cache MODERAT
E
No
 fc xx CM Temperature abnormality
warning
Cache MODERAT
E
No
 fe xx Warning for forcible volatile
mode
Cache MODERAT
E
No
Legend:
■
Yes: This SIM performs the host report.
■
No: This SIM does not perform the host report.
■
x: A hexadecimal number between 0 and f.
1. If you select All for Notication Alert in the Edit Alert Settings window, the SNMP
agent reports all SIMs. If you select Host Report, the SNMP agent reports only
SIMs that perform the host report.
2. If the DKC emulation type is I-2105 or I-2107, SIMs are reported to the host only if
SOM 308 is enabled. However, SOM 308 is disabled by default.
3. This SIM is not reported to the host, but the SNMP agent reports the SIM when
Host Report is selected for Notication Alert in the Edit Alert Settings window.
4. The SNMP agent does not report this SIM when Host Report is selected for
Notication Alert in the Edit Alert Settings window, because the SIM is reported
to the host, but not to the SVP.
5. SIMs are not reported to the host by default. To enable reporting of service SIMs,
see the Hitachi Universal Replicator for Mainframe User Guide.
6. xxx: Drive location. For details, see Converting DB and RDEV numbers to the HDD
location number (on page 88) .
Failure trap reference codes
