HITEC ECLIPSE 7 User Manual

Aircraft
(ACRO)
Section
– 33 –
10. Press the
Up
arrow once. This gets you
into the Timer menu (TIME). If you want, you
can use the
Data +Increase
or
–Decrease
keys
to select the amount of time you want the
stopwatch to count down.
11. This completes the initial part of the setup.
Now, we’ll go ahead and customize the ACRO
settings for your model. Switch transmitter
power OFF.
12. Now turn power ON. The transmitter
should display the model number and battery
voltage as shown. The number on the right is
the elapsed time, which will vary depending
on how long the transmitter has been left on.
10.3V 129
421 3 567
MODEL
13. Press both
Edit
keys to get to the regular
programming menu. The end-point adjust
menu (EPA) should appear. Press the
Down
arrow to get to the flaperon menu
(FLPN). The display should show that it is
inhibited (INH).
FLPN Inh
14. Turn on the Flaperon function by pressing
the
Active/Inhibit
button (
Clear
) until “
On
”
appears in the display.
FLPN On
CH
16
SLV
MAS
15. Be sure that you connect the right aileron
servo to receiver CH1 and the left aileron
servo to receiver CH6.
16. Later, you can get differential by adjusting
the up and down motion of the two servos in
the
FLPN
menu. Now we’ll set the servo throw
directions.
Now check that each servo moves the proper
direction. We’ll use the Reversing function if
they don’t. Go to the Reversing menu (REV)
by hitting the
Down
arrow.
REV
CH
4213567
N
R
17. We’ll start by setting the right aileron
servo direction. This is channel 1, and the
1
should be flashing for this command. When
you move the right-hand stick to the right, the
aileron on the right wing should move
upwards, and the aileron on the left should
move downward. Check that the right aileron
moves the correct way!
(Need correct drawing)
RIGHT
LEFT
F
r
o
nt
V
i
e
w
LEFT
RIGHT
18. If it does not, activate the opposite
direction for the CH1 aileron servo by pressing
the
Active/Inhibit
(
Clear
) key. Each press
switches from Reversed to Normal and from
Normal to Reversed. In the display,
N
for
Normal is chosen when the little triangle is
above the channel number, and
R
for
Reversed is chosen when the little triangle is
below the channel number. Move the right-
hand stick again and verify the right aileron
moves the right directions. The display shows
Channel 1 reversed.
REV
CH
4213567
N
R
