HITEC ECLIPSE 7 - Eclipse 7 Glider Controls and Switch Assignments

Glider
(GLID)
Section
– –
64
Eclipse 7 Glider Controls and Switch Assignments
This should be the “Eclipse 7 Mode 2 Switch Configuration List”
drawing with only the GLID features listed (less confusing).
This figure shows the assignments for a Mode 2 system as supplied by the factory for the North
American version. Note that some of the functions will not operate until activated in the mixing
menus.
