Hitron CGNVM User’s Guide
Protocol Use this field to specify whether the CGNVM should
forward traffic via:
Transmission Control Protocol (TCP)
User Datagram Protocol (UDP)
Transmission Control Protocol and User Datagram
Protocol (TCP/UDP)
Generic Routing Encapsulation (GRE)
Encapsulating Security Protocol (ESP)
NOTE: If in doubt, leave this field at its default (TCP/
UDP).
Public Port Range Use these fields to specify the incoming port range.
These are the ports on which the CGNVM receives
traffic from the originating host on the WAN.
Enter the start port number in the first field, and the end
port number in the second field.
To specify only a single port, enter its number in both
fields.
Private Port Range Use these fields to specify the ports to which the
received traffic should be forwarded.
Enter the start port number in the first field. The number
of ports must match that specified in the Public Port
Range, so the CGNVM completes the second field
automatically.
Local IP Address Use this field to enter the IP address of the computer on
the LAN to which you want to forward the traffic.
Remote IP Address Use this field to enter the IP address of the computer on
the WAN from which you want to forward the traffic.
Apply Click this to save your changes to the fields in this
screen.
Close Click this to return to the Port Forwarding screen
without saving your changes to the rule.
Table 17: The Basic: Port Forwarding Add/Edit Screen
