Configuration 3-4
© 2005 HMS Industrial Networks AB7607 User manual
Display Panes
The BWConfig display is divided into 3 panes.
Tool Operations
The following operations are available through the BWConfig menus and tool bar.
Configuration Module type and status information about the
Anybus-X module that was detected.
Ethernet Configuration Configuration of Ethernet network parame-
ters.
DeviceNet Configuration Configuration of DeviceNet network parame-
ters and status of the network interface.
New File Create a new configuration for the selected
type of module.
Open File Open a previously saved configuration.
Save File Save the current configuration to a file.
Refresh Device Status Refresh the module identity and status infor-
mation. This will update the current status
information shown by the tool. This can also
be used to start the detection process if a mod-
ule has not been detected by the tool, or the
connection has been changed to a different
module.
Upload Configuration Read the configuration that is currently stored
in the Anybus-X module. This will overwrite
any configuration that is displayed on the
tool’s user interface.
Download Configuration Send the configuration shown on the tool’s
user interface to the Anybus-X module.
Offline Configuration Offline configuration will allow a configura-
tion to be created and saved without being
connected to a module.
