Chapter 12 Connectors 12-1
© 2005 HMS Industrial Networks
AB7607 User manual
Connectors
Power
Use Phoenix connector part number MSTB 2,5/2-ST-5,08 ABGY
Figure 12-1 Power Connector
Pin Connection
1 24 VDC +
2 24 VDC Common
Table 12-1 Power Connector Pin Definitions
