HMS AnyBus-X AB7607 - Structure

File System 8-4
© 2005 HMS Industrial Networks AB7607 User manual
Structure
The figure below illustrates the structure of the file system, where the system files
are located, and which areas that can be accessed by normal/admin users.
Figure 8-1 File System Directory Structure
user
Root directory for normal users
ethcfg.cfg (Ethernet settings, IP etc)
ip_access.cfg (IP Addresses of
allowed clients)
telwel.cfg (Telnet welcome message)
onoffln.cfg (ON/OFF-line
con
f
i
g
uration
ad_pswd.cfg (Admin password file)
email_1.cfg
sys_pswd.cfg
(Normal
password file)
email_2.cfg
email_10.cfg
pswd
Root directory in admin mode
pswd
email
(User defined
email files
)
email
email_1.cfg
email_2.cfg
email_10.cfg
(Admin defined
email files
)
User1
User2
web
(Contains
Anybus-X Web
Pages)
index.htm
(default web page)
styles
(files used in
web pages)
