Power and Network Connections
The power and network connections to the Anybus-X are made on the end of the
module. Figure 2-1 indicates the location of each connector.
Figure 2-1 Anybus-X Power and Network Connections
DeviceNet Power
Aux RS-232
Ethernet
Ethernet IP Address
