Connectors 12-4
© 2005 HMS Industrial Networks AB7607 User manual
Auxiliary RS-232 9 Pin D-Subminiature
Pin Signal
1NC
2 Receive
3Transmit
4NC
5NC
6NC
7NC
8NC
9NC
Table 12-4 RS232 9 Pin
