Using the Ethernet File System
Step 1: Browse the file system
• Open a web browser window on the PC.
• Type ‘FTP://<IP address>’ in the address field. (Substitute <IP address>
with the IP address you are using for the module). (Don’t include the
“<“or “>” characters.)
• When prompted for a username enter “admin”.
• When prompted for a password enter “admin”.
You can now browse the file system. You should see subdirectories “/web”, “/
pswd” and “/user” and three files “/index.htm”, “/ehtcfg.cfg”, and “/telwel.cfg.
Step 2: Create some Files Using Telnet
• Click on the Windows ‘Start’ menu and select ‘Run.’
• Type ‘telnet <IP address>’. Substitute <IP address> with the IP address
you are using for the module. (Don’t include the “<“or “>” characters.)
Example:
telnet 65.106.35.252
• You will be prompted for a username, enter “admin”, and a password,
“admin”.
• The Telnet client will be opened, and connected to the module. You can
now browse the user file system using a command line interface.
• Type ‘help’ for a quick explanation on the available commands.
• Type ‘md mydirectory’. You have now created a directory called ‘mydi-
rectory’.
• Type ‘dir’ to view the directory.
• To move inside the directory, type ‘cd mydirectory’.
• Type ‘mkfile myfile’. You have now created an empty file called ‘myfile’.
Let’s put something in it.
• Type ‘append myfile “Easy file handling!”’. You have now added the line
‘Easy file handling!’ to your new file.
• View the files contents by typing ‘type myfile’
