Configuration 3-14
© 2005 HMS Industrial Networks AB7607 User manual
DeviceNet Network Configuration
Setting the DeviceNet Configuration with BWConfig
The DeviceNet network configuration pane in BWConfig contains the parameters
used to control the behavior of the DeviceNet network interface. The parameters
are described in Table 3-2 below. Refer to Figure 3-1 to see how each parameter is
displayed on the user interface.
Note: The Anybus-X will automatically reset after the DeviceNet configuration is
downloaded from BWConfig.
Parameter Description Allowable
Range
MAC Address The network address the Anybus-X will use
on the DeviceNet network.
The MAC address factory default is 63.
0-63
Baud Rate The baud rate of the DeviceNet network.
The baud rate factory default is 125K
125K
250K
500K
Auto Baud Enable or disable automatic baud rate detec-
tion on the Anybus-X.
The factory default setting for automatic baud
detection is Disabled.
Note: If the Anybus-X is the primary master
on the DeviceNet network, do not enable auto-
matic baud detection.
Enabled or
Disabled
Swap I/O Bytes Enable or disable I/O data byte swapping.
This option will swap bytes in the I/O tables
on 16-bit boundaries. This is helpful when
using Modbus/TCP, which expects data to be
stored in reverse byte orientation from
DeviceNet.
Do not enable byte swapping if EtherNet/IP is
used on the Ethernet side of the gateway.
Enabled or
Disabled
Table 3-2 DeviceNet Network Configuration Parameters
