12 Chapter 1: Introduction
Symbols on the rating plate
The rating plate is on the bottom of the device.
Figure 1:
SN:
CEA1700011
LAVI 40
Ventilator
Type: 9LV402
IP22
Made in Germany
HOFFRICHTER GmbH
Mettenheimer Str. 12/14
19061 Schwerin
GERMANY
O
2
-INPUT
max. 15l/min
500 hPa
Li-Ion RRC2054
15V / 3.2Ah / 48Wh
DC-INPUT
24V max. 3.75A
Rating plate
Symbol Meaning
Follow the instructions in the user’s manual.
Protection class II (protective insulation)
BF application part
IP22
Protection against:
• solid foreign objects with diameters from 12.5 mm
• access to hazardous parts with a finger
• falling/dripping water, as long as the housing is tilted up to 15°
Serial number
CE mark and number from the notified body. The medical device complies
with the applicable regulations of EU 93/42/EEC for medical products.
Manufacturer
Do not dispose of the device with the household waste. Please contact the
relevant customer services department to find out how to properly dispose
of the device.
