BF15D-BF20D
Standard
OUTER ROTOR-TO-BODY CLEARANCE
Measure the outer rotor-to-body clearance with the pump
shaft installed.
Service limit
I Standard 1 Servicelimit I
0.04 - 0.09 mm (0.002 - 0.004 in)
I 0.15 - 0.21 mm (0.006 - 0.008 in) 1 0.26 mm (0.010 in) I
0.12 mm (0.005 in)
OIL PUMP BODY 1.D
40.71 - 40.74 mm
(1.603
- 1.604 in)
40.76 mm
(1.605 in)
ROTOR-TO-BODY SIDE CLEARANCE
Measure the rotor-to-body side clearance.
I Standard 1 Service limit I
OIL PUMP BODY DEPTH
Measure the pump body depth.
I Stand a rd I Servicelimit 1
12.04 - 12.07 mm
(0.474
- 0.475 in)
12.11 mm
(0.477 in)
10-6
