CONTROLS AND FEATURES
When the engine control system
detects an engine control system
malfunction, the malfunction
indicator turns on and the buzzer
sounds at one-second intervals.
Oil Pressure Indicator
When the oil pressure indicator is lit,
oil pressure is OK.
If oil pressure becomes low, the
indicator will go off, and the engine
protection system will limit engine
speed. Refer to TAKING CARE OF
UNEXPECTED PROBLEMS, on p.
110.
All models are equipped with a
buzzer that sounds continuously
when the oil pressure indicator goes
off.
Low oil pressure indicates that the
engine oil level is low or that there is
a problem with the engine lubrication
system.
OIL PRESSURE
INDICATOR
LH and LHT Types
(GREEN)
(internal buzzer)
LRT and XRT Types
(side-mount control)
OIL PRESSURE
INDICATOR
(GREEN)
BUZZER
