83
SERVICING YOUR OUTBOARD MOTOR
Apply Honda Marine Corrosion Inhibitor (or equivalent) to all areas under the engine cover and any exposed metal
surfaces except the belts.
LOWER SWIVEL
CASE
PROPELLER SHAFT
Lubrication Points
Apply Honda Marine waterproof grease to the parts
shown below:
Lubrication interval:
After the first 20 hours or 1 month, then every 100 hours
or 6 months (refer to the maintenance schedule on page
73).
To prevent corrosion, apply anticorrosion oil to pivot
surfaces where grease cannot penetrate.
UPPER SWIVEL CASE/
MOUNT FRAME
TILLER HANDLE
(LH and LHT types)
TILT SHAFT
31ZZ46240.book Page 83 Tuesday, July 22, 2014 10:00 AM
