35
CONTROLS AND FEATURES
The cooling system indicator
discharge port can also become
plugged.
OTHER FEATURES
Overrev Limiter
The engine is equipped with an
overrev limiter to prevent the
possibility of mechanical damage
from excessive engine speed.
The overrev limiter may be activated
during operation, limiting engine
speed, if the outboard motor is
trimmed or tilted up excessively, or
when propeller ventilation occurs
during a sharp turn.
If the overrev limiter is activated,
check the trim angle of the outboard
motor.
Check to see if the correct propeller is
installed.
Portable Fuel Tank
[standard equipment (Canadian
types)]
[optional equipment (American
types)]
The portable fuel tank has a capacity
of 6.6 US gal (25 L) and has a fuel
gauge built into the fuel tank
connector.
