Honeywell | 24
6 Electrical Assembly
Figure 6.1 - Antenna Location
Connector Specifications:
HPN: 51506947-303
MPN: 73415-1472
MFGR: MOLEX LLC
Description: CONN MMCX JACK STR 50 OHM PCB
Recommended Antenna Specifications:
HPN: 50182208-001
MPN: Y4HON00A1AA_ANT_X2
Description: RF LTE Antenna (698-3000 MHz spectrum)
6.4 SIM Card
The SIM Holder (J3) on CloudLink 5G Modem holds the cellular radio Nano SIM card. CloudLink 5G
Modem supports 1.8V (Class C) version SIM cards.
Insert a SIM card in the slot provided and make sure SIM card touches the SIM card pads.
