42 107026-11-EN FR26 ROW 302 Printed in France
Power supply boards (with male plugs)
FF-SBZE130K 120/240 Vac power supply module for emitter FF-SB14 with metal plugs (DIN 43652)
FF-SBZR130K 120/240 Vac power supply module for receiver FF-SB14 with metal plugs (DIN 43652)
FF-SBZE1302K 115/120 Vac power supply for emitter FF-SB14 filtered
FF-SBZR1302K 115/120 Vac power supply for receiver FF-SB14 filtered
FF-SBZE1384 24 to 48 Vdc power supply module for emitter FF-SB14 with metal plugs (DIN 43652)
FF-SBZR1384 24 to 48 Vdc power supply module for receiver FF-SB14 with metal plugs (DIN 43652)
FF-SBZE13824 24/48 Vdc power supply module for emitter FF-SB14 filtered
FF-SBZR13824 24/48 Vdc power supply module for receiver FF-SB14 filtered
FF-SBZE147K 120/240 Vac power supply module for emitter FF-SB14 with plastic plugs (DIN 43651)
FF-SBZR147K 120/240 Vac power supply module for receiver FF-SB14 with plastic plugs (DIN 43651)
FF-SBZE1464 24 to 48 Vdc power supply module for emitter FF-SB14 with plastic plugs (DIN 43651)
FF-SBZR1464 24 to 48 Vdc power supply module for receiver FF-SB14 with plastic plugs (DIN 43651)
Note: the mode of operation may be reprogrammed before changing the power supply boards.
10. Technical specifications
Supply voltage
120/240 Vac / +10 % / -20 %
48 Hz to 62 Hz
24 Vdc to 48 Vdc* / ±15 %
Power consumption
8 VA per unit 8 W per unit
Switching capacity
2 A / 250 Vac, 2 safety relays with guided contacts (50 mA minimum)
Plastic connector Emitter: type GDM2009, Hirschmann
Receiver: type GDM2009, Hirschmann
type N6RFF, Hirschmann
Electrical connection
Metal connector DIN 43652
Material
Housing: aluminium alloy yellow painted according to RAL 1021
Front face: polycarbonate (shock and welding splash resistant for filtered versions)
Housing size
56 mm width, 116 mm depth, height according to protection height
Emission
Modulated Light Source, infrared LED (880 nm)
Scanning frequency
9,6 kHz
Scanning distance
FF-SB14E/Rooo-oo
2: 0 m to 10 m
2L: 3 m to 24 m **
2F: 0 m to 6 m
Resolution
ø35 mm minimum target size
Alignment tolerance
± 2° for emitter and receiver
Ambient temperature
0 °C to 55 °C
Sealing
IP 65
Noise immunity
Electrical noise immunity according to IEC 801-4: level IV (120/240 Vac models)
level III (24 Vdc to 48 Vdc models)
Electromagnetic noise immunity according to IEC 801-3: level III
Resistance to
ambient light
Sun: 20 000 Lux; Lamp: 15 000 Lux
Output indication
LED displays on unit front face
* The dc version is featured with a galvanic insulation (dc to dc converter) that provides the immunity to external disturbances; this is
essential to garantee the safety integrity of the device.
** Although the device is able to detect any opaque object greater than ø 35 mm resolution between 0 and 3 meters, the power of light
beams on this model requires a scanning distance of more than 3 m to conform to IEC 61496 - 2 norm. This model is available with metal
connectors only.
