6 107026-11-EN FR26 ROW 302 Printed in France
56
38
116
cross-section
Fixing grooves
in the "T" for
H.M6
or Q.M6 screws
freien Raum
für Gegenstecker
lassen
Leave room to
insert a screw-driver
All fixing items are delivered
with Onduflex elastic washers:
with pre-tightened nuts,
adjustment is still possible
81
70
ø 3.4
3.5
25
30
1515
optical axis
Amphenol-Tuchel connector (C146 type)
3.3 Range
Range: distance between emitter and receiver
L
E
R
Range:
FF-SB14E/R ❏❏❏
❏❏❏ ❏❏❏
❏❏❏ - ❏❏
❏❏❏❏
❏❏
2: 0 m to 10 m
2L: 3 m to 24 m (1)
2F: 0 m to 6 m (2)
1. although the device is able to detect any
opaque object greater than the ø 35 mm
resolution between 0 and 3 meters, the power of
light beams on this model requires a scanning
distance of more than 3 meters to conform to IEC
61496 - part 2 norm. This model is available with
metal connectors only.
2. preferred models for welding applications.
Protection
height (mm)
400 600 800 1000 1200 1400
Mass per
device (kg)
4 5,2 6,4 7,5 8,6 9,7
FSB14_10
FSB14_11
