Zones
The default setting for the zones on the Galaxy 3 Series are shown in the following table:
Table 2-6. Default Zone Functions
Zone Addresses
Each zone has a four digit address; 1004, 4136. The address is made up of three reference numbers as shown
in the following figure:
Figure 2-11. Zone Addresses
For example, zone 3057 is the detector connected to line 3, RIO 05, zone 7.
Zone Addresses
Example: 3057
Represents Panel
Line No.
Represents
RIO Address
Represents
Zone No. 1-8 on
RIO
GALAXY
G3 PANEL
1 2 3 4
RIO
ADDRESS 05
ZONE 7
3
05 7
Galaxy
Panel
Zone 1001 Zone 1002
Remaining
Zones
3-48 Final Exit Intruder
3-144 Final Exit Intruder
3-520 Final Exit Intruder
