Galaxy 3 Series Installation Manual
3-4
Entry/Exit RIO Zone Programming
Zones 1 – 5 operate as normal zones. If a zone is programmed as Security, any activation - whether the
Entry/Exit RIO is armed or disarmed and the Galaxy is set or unset - results in the appropriate alarm condi-
tion being generated on the control panel.
If zones 1 – 5 are programmed as Intruder, then an alarm condition can be generated on the Entry/Exit
RIO when it is armed and the Galaxy is unset.
Zones 6 and 7 behave as an Exit and Final zone respectively. The functioning of these zones is fixed and is
independent of the programming of the Galaxy. Zone 7 can be programmed as Log in order to report and
record its activation in the Galaxy event log.
The function of zone 8 is fixed as a Keyswitch. This should also be programmed as Log in order to report
and record its activation in the Galaxy event log.
Entry/Exit RIO Zone Operation
The Entry/Exit RIO is armed by the transition of zone 8 (the keyswitch zone) from 2 kΩ to 1 kΩ (reverse to
normal operation). This starts an exit/entry time of 30 seconds. Closing the contact on zone 7 (the Final
zone) or expiry of the exit time set the RIO. Any activation of zones 1 – 5 when the Entry/Exit RIO is
armed activates the Alarm output (output 4).
The Entry/Exit RIO is disarmed by the transition of the keyswitch zone (zone 8) from 1 kΩ to 2 kΩ. The
disarming procedure can be started by activating the final zone, (zone 7), and gaining access to the keyswitch
zone via the exit zone (zone 6). Activating zones 1–5 during the disarming period result in an alarm condition
being generated. If the Entry/Exit RIO is disarmed while the main Galaxy is set, then activation of any of its
zones programmed as Intruder does not generated an alarm condition on the RIO or the control panel; the
zones are shunted.
The exit/entry time can be changed from 30 seconds to 90 seconds by cutting resistor LK4.
Slave RIO
A RIO is configured as a Slave or Shunt RIO if resistor LK4 is cut, this allows a further sub-system to be
added to the Galaxy.
The programming and operation of the Slave RIO is identical to that of the Entry/Exit RIO except for zones
6 and 7, which are Intruder type zones by default. Slave RIOs do not have an Exit or Final zone, or an
exit time; they are instantly unset and reset by the transition from 1 to 2 kΩ of zone 8.
Table 3-5. Slave RIO Configuration
Entry/Exit RIO
enoZtluafeD
noitcnuF
demmargorP
noitcnuF
tuptuOnoitcnuFtluafeD
)dexiF(
1redurtnInoitcnufynA1ydaeR
2redurtnInoitcnufy
nA2teSotliaF
3redurtnInoitcnufynA3teS
4redurtnInoitcnufynA4mralA
5redurtnInoitcnufynA
6redurtnInoitcnufynA
7redurtnInoitcn
ufynA
8hctiwsyeKgoL
