Galaxy 3 Series Installation Manual
3-7
addresses are disabled by default.
Module status on the RF RIO such as lid tamper,will be reported to the panel using the address set on the
rotary switch.
RF RIO Programming
Programming of the RF RIO is achieved by connecting a Galaxy Mk7 keypad directly to the RF RIO at the
Programming Keypad Socket or the Keypad Connector Block. The Keypad is not part of the Galaxy net-
work and must be addressed as 0.
Note: To program RF devices, please refer to RF RIO Module, Installation and Programming
Instructions, (II1-0076) supplied with the RF RIO.
Configuring the RF RIO
The RF RIO is configured into the system on exiting from engineer mode. If the message
XX Mod Added [<],[>] To View is displayed, the system has recognised that a new module is present. Press
the A or B keys to confirm that the RF RIO has been added. If this message is not displayed or the RF RIO
is not on the list of added modules, then the RF RIO is not communicating with the control panel.
The flash rate of the red LED (LED1) on the RF RIO indicates the status of the communication with the
control panel — refer to Table 3-8.
Table 3-8. RF RIO LED flash rates
RF RIO (cont’d)
ETARHSALFGNINAEM
FFO9.-/NO1.0snoitacinummoclamroN
FFOylppus.c.doN
FFO5.1/NO5.1metsysotniderugifnocneebtonsah
OIRFR
FFO1.0/NO2.0metsyshtiwnoitacinummoctsolsahOIRFR
FFO1.0/NO9.0snoitacinummocroopyreV
