1-1
Galaxy 3 Series Installation Manual
Introduction
This manual gives full instructions required to install a Galaxy 3 Series control panel and associated
peripherals.
Throughout this Installation Manual, references to menu options, unless otherwise indicated, are found in the
Galaxy 3 Series Programming Manual, part number IP1-0033.
Variants
The Galaxy 3 Series is available in five variants: 3-48C; 3-144; 3-144C; 3-520; 3-520C. The differences
between each variant are shown in the following table:
Introduction
Table 1-1. Galaxy 3 Series Variants
NOTE: The RS485 Expansion module gives two extra lines (lines 3 and 4) on the 3-520 only.
VARIANT
ON-BOARD
COMMS
RS485 EXPANSION
MODULE
RS485 LINES
3-48C YES NO 1
3-144 NO NO 2
3-144C YES NO 2
3-520 NO YES 4
3-520C YES YES 4
