Honeywell HJZTP User Manual

Rev. 1.01 1 900.0570
8-Sept-05
SECTION 1:
INTRODUCTION
1.1 PRODUCT DESCRIPTION
The HJZTP Keyboard can control DVRs, multiplexers, and PTZs using Honeywell VCL
(Orbiter/RapidDome) or Honeywell Diamond (KD6/HD6) protocol. It can control systems
with up to a maximum of 128 PTZ cameras, 99 DVRs, and 32 multiplexers (using RS485
distribution boxes such as the HDCD8TP).
Up to four HJZTP keyboards can be connected together to providing a system
controlled by one (1) master keyboard, and three (3) slave keyboards.
RapidDome/Orbiter dome data can also be input into the keyboards. This data is then
added to the dome data output along with dome data generated by the keyboards.
Model Description
HJZTP Joystick Controller for controlling PTZs, DVRs, and
Multiplexers. Power supply requires 120 VAC.
HJZTPX Joystick Controller for controlling PTZs, DVRs, and
Multiplexers. Power supply requires 230 VAC.
1.2 COMPATIBLE PRODUCTS
The HJZTP Controller is compatible with the following products:
 Multiplexers
AXCD16E, AXCD9E, AXCD4E, AXMD16E, AXMD9E, AXMD4E
HXCT4, HXCT9, HXCT16, HXMT4, HXMT9, HXMT16
 DVRs
HRHD1, HRHD410, HRHD4, HRHD9, HRHD16
AHDR4X, AHDR9X, and AHDR16X (firmware version 2.3.2.000 or above)
 Compatible Domes
KD6, KD6i, HD6i
Orbiter Insight, Lite, Gold, Platinum
RapidDome Gold

Honeywell HJZTP Specifications

General

Brand	Honeywell
Model	HJZTP
Category	Controller
Language	English
