Rev. 1.01 31 900.0570
8-Sept-05
HONEYWELL VCL PROTOCOL, CONTINUED
6.10.1 Home
Select ‘HOME’ in the camera setup menu, then press ‘aux’ to display the home menu as
shown below:
A U X = S E T L O C K = E N D
P R E S E T T O U R O F F
To set a home preset or a home tour. Select ‘PRESET’ or ‘TOUR’ then press ‘aux’. The
home time-out menu will be displayed as below:
H O M E L O C K = E N D
E N T E R T I M E O U T n n n
nnn is the current time-out in minutes.(1 to 127.)
The time in minutes can be edited using the numeric keys. Once the time has been
entered press ‘lock’ to exit the menu.
Note: Before the Home Preset (preset 0) or Home Tour (tour 1) can function they must
first be defined. See section 6.1.7 for instruction on how to define the tours and presets.
To turn off a home preset or home tour, select ‘OFF’ in the home menu, then press ‘aux’.
‘HOME OFF’ will be displayed for 1 second to confirm the selection, as shown below:
H O M E O F F
6.10.2 Privacy Zones
Select ‘PRIVACY’ in the camera setup menu, then press ‘aux’ to display the privacy
menu as shown below:
A U X = S E T L O C K = E N D
P R E S E T n n n P R I V A C Y
nnn is the preset number. If the preset is a normal preset ‘PRESET’ will be displayed
instead of ‘PRIVACY’.
Preset numbers 100 to 127 can be set as either a privacy zone or a normal preset.
Selected the required preset number by using the joystick up and down or ‘F1’ (‘▲’),
’F2’ (‘▼’) keys. Then press the ‘aux’ key to toggle the preset status between ‘PRIVACY’
and ‘PRESET’.
Once the required privacy setup has been entered press ‘lock’ to exit the menu.
