Honeywell HJZTP User Manual

Rev. 1.01 35 900.0570
8-Sept-05
SECTION 7:
PTZ CONTROL FUNCTIONS WHEN USING HONEYWELL DIAMOND
(KD6/HD6) PROTOCOL
7.1 PTZ CAMERA SELECTION (HONEYWELL DIAMOND PROTOCOL)
The PTZs can be controlled while the keyboard is in any mode (DVR, Multiplexer, or
PTZ). The keyboard sends out standard telemetry to a dome or other receiver
connected via RS485.
Before a PTZ can be controlled it must first be selected by pressing one or two of the
number keys (to enter a legal camera number) followed by the ‘camera’ key. The
camera number that is displayed on the LCD is the camera that is being controlled.
The following functions are available:
 Variable speed pan and tilt.
 Zoom control.
 Manual and automatic iris control.
 Manual focus control.
 Preshot programming and selection.
 Vectorscan selection.
 Freeze
 Flashback
 Nightshot
 Home position selection.
 Return to manual
The keyboard can also control the on-screen display (OSD) menus on the dome.
7.2 PTZ MODE
PTZ mode changes the way the keyboard selects cameras. To toggle between PTZ
mode ON and OFF, press and hold the ‘Fn’ key, then press the ‘mode’ key.
PTZ Mode OFF (PTZ LED OFF) Selecting a camera for control will also cause a full
screen picture from that camera to be displayed
on the DVR (in DVR mode) or Multiplexer (in MUX
mode).
PTZ Mode ON (PTZ LED ON) Enables cameras to be selected for control without
changing what is displayed on the monitors.
