Honeywell IntelliPath Series User Manual

Section 3: Programming the Communicator
31
PROMPTS OPTIONS DESCRIPTION
32
Telco Zone
(0)_
Zone Trig: [3-7]
[0] = not used
See Important Information Regarding Zone Input Options on
previous page.
Enter the zone number to be used for Telco line fault reports.
This zone assignment must be unique from the open/close zone
selected in Prompt 33.
Zone Trigger Mode: If any zone is programmed for "report only if
armed," zone 7 cannot be used. If Lynx Panic is enabled,
zone 3 cannot be used.
NOTE: Connect the Telco line fault output (or relay output
programmed for "Telco line fault") to the Telco zone.
33
Open/Close Zone
(0)_
Zone Trig: [3-7]
[0] = not used
Enter the zone number to be used for open/close (arm/disarm)
reports.
This zone assignment must be unique from the Telco zone
selected in Prompt 32.
Zone Trigger Mode: If any zone is programmed for "report only if
armed," zone 7 cannot be used as an open/close zone. If
Lynx Panic is enabled, zone 3 cannot be used.
NOTE: Connect an open/close (arm/disarm) trigger (or relay
output) from the control panel to the open/close zone.
34
Zn1 Trigger Type
(V+)_
 (V+)
 (V–)
 (EOLR)
Selects the triggering method for this zone input.
Press the [space] key to scroll through the choices.
UL/UL: V+ must be set as inverted and V– as
non-inverted.
35
Restore Zn1 Y/N
(Y)_
[Y], [N]
Enables restore reporting for zone 1.
UL/ULC: Must be set to “Y.”
36
Delay Zn1 (secs)
(00)_
[01-15]
[00] = no delay
Defines the reporting delay in seconds for
zone 1.
UL/ULC: Must be set to “00.”
37
Rpt Zn1 ONLY if
Armed (N)_
[Y], [N]
Report alarms on zone 1 ONLY if the conditional zone (zone 7 in
zone trigger mode) is triggered (armed).
If [N], always reports alarms on zone 1.
38
Invert Zn2 Y/N
(N)_
[Y], [N]
Inverts the alarm and normal states of the zone 2 trigger;
otherwise uses normal input signal.
39
Restore Zn2 Y/N
(Y)_
[Y], [N]
Enables restore reporting for zone 2.
UL/ULC: Must be set to “Y.”
40
Delay Zn2 (secs)
(00)_
[01-15]
[00] = no delay
Defines the reporting delay in seconds for zone 2.
UL/ULC: Must be set to “00.”
41
Rpt Zn2 ONLY if
Armed (N)_
[Y], [N]
Reports alarms on zone 2 ONLY if the conditional zone (zone 7 in
zone trigger mode) is triggered (armed).
If [N], always reports alarms on zone 2.
If Lynx Panic is enabled, then skip to Prompt 46: "Rpt Zn3 ONLY if Armed."
42
Zn3 Trigger Type
(V+)_
 (V+)
 (V–)
 (EOLR)
Selects the triggering method for this zone input.
Press the [space] key to scroll through choices.
UL/ULC: V+ must be set as inverted and V– as
non-inverted.
43
Invert Zn3 Y/N
(N)_
[Y], [N]
Inverts the alarm and normal states of the zone 3 trigger;
otherwise uses normal input signal.
44
Restore Zn3 Y/N
(Y)_
[Y], [N]
Enables restore reporting for zone 3.
UL/ULC: Must be set to “Y.”
45
Delay Zn3 (secs)
(00)
[01-15]
[00] = no delay
Defines the reporting delay in seconds for zone 3.
UL/ULC: Must be set to “00.”
