ID3000/ID2000 Fire Panel Configuration Tool Manual
Additional Logic Example
A3 - 1
997-291, Version 3.05
November 2010
Appendix 3: Additional Logic Example
Note: This example can only be configured if
the panel software version is 4.35 or
above (see lamp test).
It may be required to configure the Control Matrix
so that a rule will only operate if certain other
rules have not already operated.
In this example there are five zones. An alarm
in any zone will operate a specific control
module, e.g. an alarm in zone 3 will operate
control module 3. After this has occurred, a
subsequent alarm in any of the other zones
does not result in its corresponding control
module operating. The output from zone 3
remains active until the panel is reset.
Note: The zone numbers, flag numbers and
module numbers used in the example
are arbitrary, and the rules can be entered
into the Control Matrix in any order (rule
numbers are given in the example solely
so that they can be referred to in the
manual).
More than one group of inputs and outputs can
be configured to operate in this mutually-
exclusive manner, but for each the rules must
be configured as follows:
(continued)
