1) INTRODUCTION
The extremely innovative and versatile NFG-8 gas detection control unit is the ideal solution for
small systems with up to 16 gas detectors.
The system provides for the connection of 8 detectors with 4-20mA output directly to the control
unit. Each input can be configured for different types of gas: toxic, refrigerant, flammable and for
oxygen, both for deficiency and enrichment.
The backlit display provides an accurate indication of gas concentration and allows the display
of set alarm levels.
The control unit manages up to 22 relay outputs, 6 of which are on board the control unit and the
other 16 through the card.
NFG-16REL
The control unit is supplied in an ABS case and can contain 2 batteries of 12Vdc, 7Ah to ensure
the operation of the system even in case of power failure.
NFG-8 is, at the date of issue of this manual, under SIL1 and ATEX certification according to EN
60079-29-1.
Other features of the NFG-8 control unit, are:
• Event memory can be consulted from display or downloaded to PC from 1,000 events.
• USB and RS232 serial ports for connection to PC for programming and management using
PK-NFG-8 software.
Central unit and accessories ordering codes
CODE
DESCRIPTION
NFG-8
Central NFG-8
8 4-20mA analogue inputs and 6 output relays on board.
+ 16 optional relays by means of NFG-16REL module to be installed on board the
control unit.
NFG-16REL
16 relay board for NFG-8
1.1) Technical specifications
Technical specifications
Housing:
Plastic box IP 42 dim 420x380x160 mm
Inputs:
Max. 8 detectors
Get out:
6 relays in control unit with contact rating 8 A - 250 Vac
16 relays through the NFG-16REL board to be connected inside the
control unit with contact rating 6 A - 250 Vac
Serial / USB ports
1 x RS232 and 1 x USB port (both for PC connection)
Power supply:
100-240Vac +/- 15%, 10A 50-60Hz
Current:
750mA @ 220Vac
Battery charger:
27,6Vdc 5,4A max total
Output Utilities
2 outputs with 27,6Vdc 1A each
Display:
LCD liquid crystal display with Backlite, 4 lines of 16 characters
Optical indications:
Double row of 9 LEDs
Operating temp:
0 ÷ 55°C
Storage temp:
-20 ÷ +60 C°
RH operation:
15 ÷ 85%
RH storage:
5 ÷ 85% (not condensing)
Weight
Central unit without batteries: 4 kg
