Honeywell Notifier NFG-8

NFG-8
NFG-8_manu-inst_ITA
Installation and Operation
Manual Doc. M-040.1-NFG8-EN
Rev A.3
PAGE - 11
NOTIFIER ITALY
2.1.1) Central overall view and identification of parts.
1-
2-
3-
Power supply (27 Vdc 4A)
Batteries 2 x 12V 7Ah (not
included) RS232 and USB serial
port
4-
5-
6-
Relay outputs
(6)
8 inputs 4-
20mA
RS485 bus
connection
Fig. 2-3) Central overview and parts identification
