UDACT Instruction Manual — P/N 50050:M 12/18/2009 39
4+2 Standard and 4+2 Express Formats Programming Instructions
3.6 4+2 Standard and 4+2 Express Formats
3.6.1 Primary Number
If “1”, “A” or “C” are entered for address 16, the following data is automatically programmed for the primary
phone number event codes. Enter a “0” for the data setting to disable the report. These formats do not
support zone/point programming. For zone/point reporting, refer to Contact ID.
Table 3.4 Event Codes, Primary Number
Address Description Setting
69-70 Primary # General Alarm Code 11
71-72 Primary # Zone/Point Alarm Code 00
73-74 Primary # General Supervisory Code 81
75-76 Primary # Zone/Point Supervisory Code 00
77-78 Primary # General Fault Code F1
79-80 Primary # AC Fault Code F6
81-82 Primary # Zone/Point Fault Code 00
83-84 Primary # Low Battery Fault Code F8
85-86 Primary # Telco Primary Line Fault Code FA
87-88 Primary # Telco Secondary Line Fault Code FB
89-90 Primary # NAC Fault Code FC
91-92 Primary # Comm. Trouble Primary # Code FD
93-94 Primary # Comm. Trouble Secondary # Code FE
95-96 Primary # 485 Comm. Trouble Code FE
97-98 Primary # System Off Normal Code FF
99-100 Primary # UDACT Off Normal Code FF
101-102 Primary # General Alarm Restore Code E1
103-104 Primary # Zone/Point Alarm Restore Code 00
105-106 Primary # General Supervisory Restore Code E2
107-108 Primary # Zone/Point Supervisory Restore Code 00
109-110 Primary # General Fault Restore Code E3
111-112 Primary # AC Fault Restore Code E6
113-114 Primary # Zone/Point Fault Restore Code 00
115-116 Primary # Low Battery Fault Restore Code E8
117-118 Primary # Telco Primary Line Fault Restore Code EA
119-120 Primary # Telco Secondary Line Fault Restore Code EB
121-122 Primary # NAC Fault Restore Code EC
123-124 Primary # Comm.Trouble Primary Number Restore Code ED
125-126 Primary # Comm. Trouble Secondary Number Restore Code EE
127-128 Primary # 485 Comm. Trouble Restore Code EE
129-130 Primary # System Off Normal Restore Code EF
131-132 Primary # UDACT Off Normal Restore Code EF
133-134 Primary # System 24 Hour Test 99
135-136 Primary # System 24 Hour Test w/active event 91
137-138 Primary # Manual Test 92
NOTE: Zero entries prevent the transmission of the report to the Central Station.
