54 UDACT Instruction Manual — P/N 50050:M 12/18/2009
Operating Instructions Troubleshoot Mode
4.2.1 Disabling of Zones or Points
This feature is primarily used when system points have been defined as remote reset, acknowledge,
silence or drill switches. Refer to the FACP technical manual for additional information.
Activation of remote switches appear as alarms on the EIA-485 bus. The UDACT will report these
points as fire alarm points unless disabled in the Type Mode. Disabling zones or points also
prohibits the activation (shorted or alarm activated condition) from being reported by the UDACT.
Disabling of the zone or point does not affect the reporting of the zone or point trouble condition.
4.2.2 Zone or Point Supervisory
A zone or point must be defined as supervisory to allow the UDACT to identify the correct report
to transmit to the central station. Follow the programming instructions in the FACP manual to
program a zone or point as supervisory. Next, program the zone or point as a code 2 for
supervisory. Use the charts in the appendices applicable to your FACP to enter point and zone
definitions.
4.3 Troubleshoot Mode
Once in this mode, the UDACT will:
• Transmit the 'UDACT Off Normal' message to the Central Station(s).
• Continue to communicate any events not yet acknowledged at the Central Station prior to
entering Troubleshoot Mode.
The
UP, DOWN and 1ST EVENT keys do not function in this mode.
4.3.1 Telephone Line Testing
Pressing C for touchtone dialing or D for rotary dialing, followed by ENTER/STORE causes seizure
of the primary phone line which in turn lights the red LED signifying Primary phone line active.
After a delay of three seconds, the UDACT goes off hook to acquire a dial tone.
The keypad may be used as a telephone touchpad for number dialing. Once the first digit is
pressed, the display will move the C or D character one position to the left, while placing the digit
to be dialed on the farthest right display position. Continue to press the phone numbers to be
dialed. Successive depressions of the
ENTER/STORE key hangs up and picks up the phone (places
the phone on or off the hook).
The secondary phone line may be tested by pressing the E key for touchtone dialing or the F key
for rotary dialing and then following the same procedure used for the primary phone line.
NOTE: Programming “6” into Host Panel ID address 63 selects an AFP-200 as the host panel. This
selection automatically programs Type Mode “1” for zones 90-99 which disables reports for these
zones. To transmit reports for zones 90-99, use Type Mode entries of “0” or “2” through “F”.
NOTE: To access Troubleshoot Mode, press MODE, then 8768, then ENTER/STORE. 8768 spells
TROU on a Touch-Tone® phone.
