UDACT Instruction Manual — P/N 50050:M 12/18/2009 57
Data Reporting Structure Reporting Formats
Letter codes for Table 5.1 on page 56:
Table 5.2 Letter Code Definitions
SSS or
SSSS
= Subscriber ID
A = Alarm (1st digit)
A2 = Alarm (2nd digit)
RA = Alarm Restore (1st digit)
RA2 = Alarm Restore (2nd digit)
TZ =Zone Trouble (1st digit)
TZ2 =Zone Trouble (2nd digit)
RTZ =Zone Trouble Restore (1st digit)
RTZ2 =Zone Trouble Restore (2nd digit)
TS =System Trouble (1st digit)
TS2 =System Trouble (2nd digit)
RTS =System Trouble Restore (1st digit)
RTS2 =System Trouble Restore (2nd digit)
L =Low Battery (1st digit)
L2 =Low Battery (2nd digit)
RL =Low Battery Restore (1st digit)
RL2 =Low Battery Restore (2nd digit)
P =AC Loss (1st digit)
P2 =AC Loss (2nd digit)
RP =AC Loss Restore (1st digit)
RP2 =AC Loss Restore (2nd digit)
V =Supervisory Condition (1st digit)
V2 =Supervisory Condition (2nd digit)
RV =Supervisory Condition Restore (1st digit)
RV2 =Supervisory Condition Restore (2nd digit)
X =Test Report (1st digit)
X2 =Test Report (2nd digit)
XA =Test Report Restore (1st digit)
XA2 =Test Report Restore (2nd digit)
