Honeywell PC42T User Manual

Chapter 1 — About the Printer
10 PC42t Desktop Printer User Guide
Load External Media
You can place the media supply, such as fanfold tickets or tags, behind
the printer. You need to purchase an external media holder separately.
1 Place the media behind the printer.
2 Feed the media into the printer through the external media feed slot.
3 Thread the media through the printer and adjust the media holders
and sensor as you would for media that loads inside the printer.
Load Ribbon
You need to use thermal transfer ribbon to print on thermal transfer
media. Make sure to select ribbon that matches the face materials of the
media to obtain the best durability and print quality.
Note: Make sure to protect the media from direct sunlight and from
dust, dirt, or other foreign particles that can impair the printout quality or
cause unnecessary wear to the printhead.
External media
feed slot
Note: The PC42t can only use ribbon that is “ink out,” which means that
the ribbon is loaded with the inked side (the dull side) facing out.

Honeywell PC42T Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104.1 mm
Certification	UL, cUL, cULus, CE, FCC, D Mark CCC, KCC, RCM
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, EAN13, EAN8, MaxiCode, QR Code
Display	LED
Product color	Black
Ethernet LAN	Yes
Optional connectivity	Ethernet, Parallel, Serial (RS-232)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ribbon width	109.2 mm
Core diameter	25.4 mm
Ribbon length	300 m
Maximum label width	110 mm
Maximum media length	9.6 mm
Maximum roll diameter	127 mm
Supported paper width	25.4 - 110 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output current	2.5 A
AC adapter output voltage	24 V
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	297 mm
Width	226 mm
Height	177 mm
Weight	2500 g
