Honeywell PC42T User Manual

Appendix B — Default Settings
PC42t Desktop Printer User Guide 53
General System Settings
This section describes general system settings. To view these settings:
• From the printer web page, click the Configure tab > System
Settings > General.
General System Settings
Setting Description Default
System Name Sets the network identification name (WINS
name) of the printer.
Printer model number
plus the serial number.
For example,
PC42-14295B1F48
System Location Sets the location of the printer. Empty string
System Contact Sets the name of the printer administrator. Empty string
Display Language Selects the language the printer uses to print
text on the test labels.
Simplified Chinese
Display Language
(Web Page)
Selects the language the printer uses to display
text on the web page.
Simplified Chinese
Keyboard Input Selects the language of the external keyboard
that is connected to the printer.
U.S./U.K.
Time Sets the current time. System time
Command
Language
Sets the printer command language. If
changed, it requires a restart of the printer.
Direct Protocol
Unit of Measure Selects the unit of measure that is used to
define several printing parameters.
Dots
Zero with Slash Determines how zero is printed or displayed on
the screen. Disable is zero (0), Enable is (Ø).
Disable (0)

Honeywell PC42T Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104.1 mm
Certification	UL, cUL, cULus, CE, FCC, D Mark CCC, KCC, RCM
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, EAN13, EAN8, MaxiCode, QR Code
Display	LED
Product color	Black
Ethernet LAN	Yes
Optional connectivity	Ethernet, Parallel, Serial (RS-232)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ribbon width	109.2 mm
Core diameter	25.4 mm
Ribbon length	300 m
Maximum label width	110 mm
Maximum media length	9.6 mm
Maximum roll diameter	127 mm
Supported paper width	25.4 - 110 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output current	2.5 A
AC adapter output voltage	24 V
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	297 mm
Width	226 mm
Height	177 mm
Weight	2500 g
