Honeywell PD45 User Manual

PD45S User Guide 13
To load media for tear off printing:
1. Open the media cover
2. Remove the media roll lever.
3. Load the media onto the media supply hub.
Note: Make sure you push the roll all the way against the inner wall of the printer.
4. Replace the media roll lever in the upright position to hold the media on the
supply hub and tighten the screw.
Warning: The tear bar contains sharp edges. Keep fingers and other body
parts away from the tear bar.
Warning: Moving parts are exposed when the cover is open. Make sure
the cover is closed before operating the printer.

Honeywell PD45 Specifications

General

Print Technology	Direct Thermal / Thermal Transfer
Ribbon Core	1 inch (25.4 mm)
Print Resolution	203 dpi
Max Print Width	4.25 inches (108 mm)
Max Print Speed	8 ips (203 mm/s)
Connectivity	USB 2.0, RS-232, Ethernet
Media Handling	Label gap, label black mark
Media Thickness	0.0025 inch to 0.01 inch (0.0635 mm to 0.254 mm)
Ribbon Width	1 inch to 4.33 inches (25.4 mm to 110 mm)
Ribbon Length	984 feet (300 meters)
Operating Temperature	5°C to 40°C (41°F to 104°F)
Power Requirements	100-240 VAC, 50/60 Hz
Media Width	25.4 mm (1 in) to 118 mm (4.65 in)
