PD45 User Guide 47
Troubleshoot Printer Problems and Find Solutions
Use this section to find possible solutions to printer problems.
Print Problems
Problem Possible Solution
The printout is weak Try these possible solutions in order:
• Make sure that your media > print quality setting is
appropriate for the type of media you are using.
• The contrast may be too low. Increase the contrast.
• The printhead pressure may be too low. Increase the
printhead pressure.
• Replace the printhead.
The printout is weaker on one
side
Adjust the printhead balance.
There are weak spots on the
printout.
Try these possible solutions in order:
• There may be foreign particles on the media. Clean or replace
the media.
• Make sure that your media and ribbon are compatible.
• Make sure that you are using high quality media and ribbon.
• The contrast may be too low. Increase the contrast.
The printout is dark or there is
excessive bleeding on the
media
Try these possible solutions in order:
• Make sure your media > print quality setting is appropriate for
the type of media you are using.
• The contrast may be too high. Decrease the contrast.
• The printhead pressure may be too high. Decrease the
printhead pressure.
There are dark lines along the
media path
The printhead may be dirty. Clean the printhead.
There are white vertical lines on
the printout
Try these possible solutions in order:
• The printhead may be dirty. Clean the printhead.
• There may be missing dots on the printhead. Replace the
printhead.
Part of a dotted line is missing Try these possible solutions in order:
• The printhead may be failing. Replace the printhead.
The inner edge of the printout is
missing
Try these possible solutions in order:
• The media may not be properly installed or aligned. Reload the
media.
• The media margin or X-start parameter may be set too low.
Increase the setting.
The content on the printout is
compressed
The print speed may be too high. Lower the print speed or adjust
the printhead pressure.
Nothing shows up on the
thermal transfer printout.
The ink-coated side of the ribbon may not be facing the media.
Reload the ribbon.
The ribbon breaks Try these possible solutions in order:
• Make sure your media setting is appropriate for the type of
media you are using.
• Make sure that the ribbon is fitted correctly. Reload the
ribbon.

Honeywell PD45 Specifications

General

Print Technology	Direct Thermal / Thermal Transfer
Ribbon Core	1 inch (25.4 mm)
Print Resolution	203 dpi
Max Print Width	4.25 inches (108 mm)
Max Print Speed	8 ips (203 mm/s)
Connectivity	USB 2.0, RS-232, Ethernet
Media Handling	Label gap, label black mark
Media Thickness	0.0025 inch to 0.01 inch (0.0635 mm to 0.254 mm)
Ribbon Width	1 inch to 4.33 inches (25.4 mm to 110 mm)
Ribbon Length	984 feet (300 meters)
Operating Temperature	5°C to 40°C (41°F to 104°F)
Power Requirements	100-240 VAC, 50/60 Hz
Media Width	25.4 mm (1 in) to 118 mm (4.65 in)
