CHAPTER
5
PD45 User Guide 43
TROUBLESHOOTING
System Information
Look in the System Information tab on the printer web page for useful information
and statistics on the printer hardware and firmware.
Statistics
Use the printer web page to view important statistics about your printer.
1. Open a web browser on your PC.
2. In the address bar, type the IP address of your printer and press Enter. The
printer web page appears.
3. Click the System Information tab.
4. Click Statistics > System Information. The System Information page appears.
5. For more detailed statistics, click another choice in the Statistics list.
Statistic Type Information Available
System Information Printer uptime and CPU usage, firmware and kernel versions, printer
configuration and serial numbers, flash and RAM memory information
Supply Printhead and ribbon information
Hardware Options Input/output devices, serial port information
Network Interfaces MAC address and TCP/IP information
Font Information Name, type, location, and size of installed fonts
Barcode Information Name and type of installed barcode fonts
Image Information Name, type, location, and size of installed images

Honeywell PD45 Specifications

General

Print Technology	Direct Thermal / Thermal Transfer
Ribbon Core	1 inch (25.4 mm)
Print Resolution	203 dpi
Max Print Width	4.25 inches (108 mm)
Max Print Speed	8 ips (203 mm/s)
Connectivity	USB 2.0, RS-232, Ethernet
Media Handling	Label gap, label black mark
Media Thickness	0.0025 inch to 0.01 inch (0.0635 mm to 0.254 mm)
Ribbon Width	1 inch to 4.33 inches (25.4 mm to 110 mm)
Ribbon Length	984 feet (300 meters)
Operating Temperature	5°C to 40°C (41°F to 104°F)
Power Requirements	100-240 VAC, 50/60 Hz
Media Width	25.4 mm (1 in) to 118 mm (4.65 in)
